Colour Laser Plotter - MFD

• KIP KC 80
• KIP 2100

KIP KC 80

Crats brings KIP KC 80 from Japan - Next Generation wide format colour LED printer and KIP 2100 Scanner which gives complete MFD Solution - Printer/Copier/ Scanner

KIP KC 80 Printer - KIP 2100 Scanner - Request Controller - KIP Rip SW – PDF Drivers PS3 Drivers – WEB Based Printing - Folder - Stacker

The world of wide format color has never seen production like this. The KIP Color 80 print system is designed for printing professionals who require high speed production of color documents, business communications and display graphics. The system is a comprehensive solution for wide format color imaging; spanning the full spectrum of applications from architectural, engineering, and construction documents to posters, signs, and photo enlargements— with maximum quality and performance.v

KIP KC 80 for all Colour Applications

Advantages

• Network & Web Enabled Colour LED (Laser) Wide Format Printing.
• High Speed Printing – 4 Mtrs, 36 Sq Ft per Minute at any density.
• Water Proof Print.
• UV Protected prints for Outdoor application (Avoids fading of prints).
• Very Low Running Cost helps replace all B&W to Colour prints.
  - Rs. 20.00 for Colour Line Drawings.
  - Rs. 70.00 for Semi Graphics & GIS images.

Features

• Upgrade to Digital Colour Copier with Enlargement and Reduction.
• Upgrade to Color Scanning system.
• KIP Rip for High end Graphic Printing.
• LOG and Security.
• Post Script III & PDF Printing.

Cost Savings

• ROI for the KIP KC 80 is 3 Years (Calculations @ 50 prints/day).
• Saving after 3 Years is minimum 35 to 40 Lakhs.
• Depreciation value saved per year – 25-30 Lakhs.
• Saves 15-20 % wastage cost which is spent in other technology printing.
• Saves on Media cost as KC 80 prints on normal media available in Local market.

Time Savings

• Removes all bottle necks in Colour Printing & Copying.
• Capacity to print 1500 A0 / 20,000 Sq. Ft. Colour prints per day.
• 600 Meters of media handling capacity, which saves time in Media handling.

No Wastage

• No paper or ink wastage due to end of paper half way
• No Ink wastage due to drying of ink in the print head
• No frequent change of Print head.

Owning KIP KC 80 Gives better branding, Innovation, Faster turnaround time, Accelerate Business Opportunities, sharing Ideas & drawings distinctively , etc.

KC 80 Printer

• Full color CMYK and monochrome dry toner LED electrostatic printer.
• 600 x 600 DPI print resolution.
• 4 media decks
  • Bond 58g/m2 – 104g/m2.
  • Vellum 59g/m2 – 78g/m2.
  • Film 3mil (76µm) – 4mil (100µm) Matte polyester.
  • Photo gloss.
• 80mm/sec process speed.
• 5 A1(Landscape) size prints per minute, 3 A0 prints per minute.
• Toner level indicator for Cyan, Magenta, Yellow and Black.
• Media level and media type indicator.
• Jam location diagram.
• 5 level density settings for individual Cyan, Magenta, Yellow and Black.
• Manual sheet bypass for A2(Landscape) up to A0.
• Cut lead edge for each roll deck.

Advantages of KIP Color 80

• Laser Quality 36 inches / 6 Meter Length Prints.
• First Toner based printing technology in wide format.
• UV Protected Print Output which avoids fading of prints.
• Water Resistance printout from KC 80.
• Heavy Duty Printers which can give output 180 Meters/hr, 1400 Meters/day, 35000 Meters per Month
• 4 Roll Decks which will hold 150 Meters * 4 = 600 Meters of Media at a time. Avoids downtime for change of media frequently.
• Excellent Sharpness of Images helps to in Multipurpose Printing – Images, CAD, 3D Images, Maps, GIS, Posters, Circuit Drawings etc. With high precision and Quality.
• Colour Calibrations and Colour Management – Supports ICC Colour Profile & full support of L*a*b.
• Cost is very much lesser that Inkjet prints – Inkjet cost – Line drawing – Rs.150/-, GIS – 450/- and Full Image – 650/-  same prints will cost Rs.16/-, Rs.35/- & Rs.70/- respectively.
• Savings – This machine ROI is 3 years and after which the Government will save 35 Lakhs annually.
• Upgradable to Multi Functional System – Color Printing, Color Scanning, Color Copying, Post Script Level III, PDF Printing, Graphics Printing, Print Net Printing via WEB etc.
• Minimum Manpower required to take huge volumes of Prints from the KIP Color 80.

KC 80 Image Processing System

The KC 80 Image Processing System (IPS) includes a color and monochrome file RIP built on a Quad Core processor with Windows XP Embedded operating system. Utilize the optional KIP CM Request and KC 80 RIP functions to take advantage of the high-speed processor and large disk space.

Standard features of the KC 80 Image Processing System:

• Print Queue
• Color and monochrome RIP and print.
• Delete print job.
• Adjust print job priority.
• Adjust print job quantity,accounting data, media type.
• Edit media type names.
• View toner level.
• View media level.

Supported File Formats

• Color File Formats: TIF, HPGL, HPGL/2, HP-RTL, DWF
• Color Photographic File Formats: JPG, JPG 2000
• Web Color File Formats: PNG, BMP, GIF, TGA, PCX, RLC/RLE
• Monochrome File Formats: TIF Group 3/4, Cals Group 4, HPGL, HPGL/2, HP-RTL, DWF, Calcomp, IBM IOCA, Intergraph CIT/TG4.
• Optional Postscript, PDF, EPS via KIP CM Postscript/PDF option.

Network Printing

• Direct printing of supported color and monochrome file formats from Unix, Macintosh, and 3rd party applications via KIP API.
• 20 Print Queue configurations for scaling, copy count, fold parameters, and stamping.

KIP CM HDI AutoCAD Driver

• Compatible with AutoCAD 2004 – 2008.
• Color and monochrome HPGL/2 – HP-RTL output.
• Select media type, copy count, accounting data, and color filter.
• Bi-directional communication for printer status, stamps, color filters, job accounting for data tracking, and real-time media supply and print meter.

IPS Hardware Specifications

• Dell 840 System Server with Quad Core Intel Xeon 2.4 GHz processor.
• 2.0 Gb DDR2, 667 MHz RAM.
• Two – 146 Gb, 15,000 RPM, SAS Hard Disk Drives – 3 Gbps transfer rate.
• 10/100/1000 Integrated RJ-45 Network Connection.
• CD/DVD Reader.
• 3 Year Dell Warranty.
• High Speed LVDS PCI-X Interface Board

Time Analysis

INKJET TECHNOLOGY	KIP COLOR 80
GOOD HEAVY DUTY INKJET PLOTTER – 5000 / 5500 SERIES	KIP LED PRINTER
150 Sq Ft PER Hr	3.6 Meters per Minute
12 A0 per hr	180 A0 per hour
100 A0 per day	1400 A0 or 3 ft / 4 ft per day
KIP Color 80 Production Speed is 140 Times faster than Inkjet.
Needs 14 days to print the same volume i.e. 1400 A0 or 3 ft / 4 ft images.
Man-hour saved using KIP Color 80 per day – 15 hrs.
Man-hour saved per month – 375 hrs.
Man hour saved in a Year – 4500 hrs in 8 hr shift per day.
Time is Directly Proportional to Money.

KIP 2100
